Segmentation

Three clusters, one predictive law

Simulation

library(glmtree)
data = generateData(n = 1000, scenario = "no tree", visualize = TRUE)

int_train = sample.int(n = 1000, size = 0.2*1000)

test = data[-int_train,]
data = data[int_train,]

PCA

library(FactoMineR)
mixed = PCA(data[,c("x1","x2")])

data$pca1 = predict(mixed, data)$coord[,1]
data$pca2 = predict(mixed, data)$coord[,2]
test$pca1 = predict(mixed, test)$coord[,1]
test$pca2 = predict(mixed, test)$coord[,2]

data$cluster = ifelse(data$pca1 > 1, 1, ifelse(data$pca1 > 0, 2, 3))
test$cluster = ifelse(test$pca1 > 1, 1, ifelse(test$pca1 > 0, 2, 3))

pred = matrix(0, nrow = 0.2*1000, ncol = 1)

for (j in 1:3) {
  modele = glm(y ~ x1 + x2, data = data[data$cluster==j,], family=binomial(link = "logit"))
  pred[test$cluster==j] = predict(modele, test[test$cluster==j,], type="response")
}

normalizedGini(test$y,pred)

## [1] 0.6604591

plot(mixed, choix = 'ind', label = "none")

MOB

if (require(partykit, quietly = TRUE)) {
  mob_data = partykit::glmtree(formula = y ~ x1 + x2 | x1 + x2, data = data, family = binomial)
  plot(mob_data)
  normalizedGini(test$y, predict(mob_data,test))
}

##
## Attaching package: 'partykit'

## The following object is masked from 'package:glmtree':
##
##     glmtree

## [1] 0.6793697

`glmtree` approach

tree = glmtree::glmtree(x = data[,c("x1", "x2")], y = data$y)

## The bic criterion for iteration 1 is 0

## The bic criterion for iteration 2 is -225.650543595755

## The bic criterion for iteration 3 is -225.650543595755

## The bic criterion for iteration 4 is -225.650543595755

## The bic criterion for iteration 5 is -225.650543595755

## The bic criterion for iteration 6 is -225.650543595755

## The bic criterion for iteration 7 is -225.650543595755

## The bic criterion for iteration 8 is -225.650543595755

## The bic criterion for iteration 9 is -225.650543595755

## The bic criterion for iteration 10 is -225.650543595755

## The bic criterion for iteration 11 is -225.650543595755

## The bic criterion for iteration 12 is -225.650543595755

## The bic criterion for iteration 13 is -225.650543595755

## The bic criterion for iteration 14 is -225.650543595755

## The bic criterion for iteration 15 is -225.650543595755

## The bic criterion for iteration 16 is -225.650543595755

## The bic criterion for iteration 17 is -225.650543595755

## The bic criterion for iteration 18 is -225.650543595755

## The bic criterion for iteration 19 is -225.650543595755

## The bic criterion for iteration 20 is -225.650543595755

## The bic criterion for iteration 21 is -225.650543595755

## The bic criterion for iteration 22 is -225.650543595755

## The bic criterion for iteration 23 is -225.650543595755

## The bic criterion for iteration 24 is -225.650543595755

## The bic criterion for iteration 25 is -225.650543595755

## The bic criterion for iteration 26 is -225.650543595755

## The bic criterion for iteration 27 is -225.650543595755

## The bic criterion for iteration 28 is -225.650543595755

## The bic criterion for iteration 29 is -225.650543595755

## The bic criterion for iteration 30 is -225.650543595755

## The bic criterion for iteration 31 is -225.650543595755

## The bic criterion for iteration 32 is -225.650543595755

## The bic criterion for iteration 33 is -225.650543595755

## The bic criterion for iteration 34 is -225.650543595755

## The bic criterion for iteration 35 is -225.650543595755

## The bic criterion for iteration 36 is -225.650543595755

## The bic criterion for iteration 37 is -225.650543595755

## The bic criterion for iteration 38 is -225.650543595755

## The bic criterion for iteration 39 is -225.650543595755

## The bic criterion for iteration 40 is -225.650543595755

## The bic criterion for iteration 41 is -225.650543595755

## The bic criterion for iteration 42 is -225.650543595755

## The bic criterion for iteration 43 is -225.650543595755

## The bic criterion for iteration 44 is -225.650543595755

## The bic criterion for iteration 45 is -225.650543595755

## The bic criterion for iteration 46 is -225.650543595755

## The bic criterion for iteration 47 is -225.650543595755

## The bic criterion for iteration 48 is -225.650543595755

## The bic criterion for iteration 49 is -225.650543595755

## The bic criterion for iteration 50 is -225.650543595755

## The bic criterion for iteration 51 is -225.650543595755

## The bic criterion for iteration 52 is -225.650543595755

## The bic criterion for iteration 53 is -225.650543595755

## The bic criterion for iteration 54 is -225.650543595755

## The bic criterion for iteration 55 is -225.650543595755

## The bic criterion for iteration 56 is -225.650543595755

## The bic criterion for iteration 57 is -225.650543595755

## The bic criterion for iteration 58 is -225.650543595755

## The bic criterion for iteration 59 is -225.650543595755

## The bic criterion for iteration 60 is -225.650543595755

## The bic criterion for iteration 61 is -225.650543595755

## The bic criterion for iteration 62 is -225.650543595755

## The bic criterion for iteration 63 is -225.650543595755

## The bic criterion for iteration 64 is -225.650543595755

## The bic criterion for iteration 65 is -225.650543595755

## The bic criterion for iteration 66 is -225.650543595755

## The bic criterion for iteration 67 is -225.650543595755

## The bic criterion for iteration 68 is -225.650543595755

## The bic criterion for iteration 69 is -225.650543595755

## The bic criterion for iteration 70 is -225.650543595755

## The bic criterion for iteration 71 is -225.650543595755

## The bic criterion for iteration 72 is -225.650543595755

## The bic criterion for iteration 73 is -225.650543595755

## The bic criterion for iteration 74 is -225.650543595755

## The bic criterion for iteration 75 is -225.650543595755

## The bic criterion for iteration 76 is -225.650543595755

## The bic criterion for iteration 77 is -225.650543595755

## The bic criterion for iteration 78 is -225.650543595755

## The bic criterion for iteration 79 is -225.650543595755

## The bic criterion for iteration 80 is -225.650543595755

## The bic criterion for iteration 81 is -225.650543595755

## The bic criterion for iteration 82 is -225.650543595755

## The bic criterion for iteration 83 is -225.650543595755

plot(unlist(tree@performance$criterionEvolution), type="l")

data$c_map <- factor(apply(predict(tree@best.tree$tree,data,type="prob"),1,function(p) names(which.max(p))))
test$c_map <- factor(apply(predict(tree@best.tree$tree,data,type="prob"),1,function(p) names(which.max(p))))

table(data$c_map)

##
##   4
## 200

plot(data[,1],data[,2],pch=2+data[,3],col=as.numeric(data$c_map),xlab="First coordinate",ylab="Second coordinate")

plot(tree@best.tree$tree)

pred = matrix(0, nrow = 0.2*1000, ncol = 1)

for (j in levels(data$c_map)) {
  modele = glm(y ~ x1 + x2, data = data[data$c_map==j,], family=binomial(link = "logit"))
  pred[test$c_map==j] = predict(modele, test[test$c_map==j,], type="response")
}

normalizedGini(test$y,pred)

## [1] 0.6793697

One “cluster”, three predictive laws

Simulation

data = generateData(n = 1000, scenario = "tree", visualize = TRUE)

int_train = sample.int(n = 1000, size = 0.2*1000)

test = data[-int_train,]
data = data[int_train,]

PCA

mixed = FAMD(data[,c("x1","x2","x3")])

dim_famd = predict(mixed,test)$coord[,"Dim 1"] < 0

pred = matrix(0, nrow = 0.2*1000, ncol = 1)

for (j in c(TRUE,FALSE)) {
  modele = glm(y ~ x1 + x2 + x3, data = data[dim_famd==j,], family=binomial(link = "logit"))
  pred[dim_famd==j] = predict(modele, test[dim_famd==j,], type="response")
}

normalizedGini(test$y,pred)

## [1] 0.1205429

MOB

if (require(partykit, quietly = TRUE)) {
  mob_data = partykit::glmtree(formula = y ~ x1 + x2 +x3 | x1 + x2 + x3, data = data, family = binomial)
  plot(mob_data)
  normalizedGini(test$y, predict(mob_data,test))
}

## [1] 0.4322791

`glmtree` approach

tree = glmtree::glmtree(x = data[,c("x1", "x2", "x3")], y = data$y)
